HTN LCD Display

Power Meters Reflective Indicator HTN LCD

Power Meters Reflective Indicator HTN LCD

Display Type:HTN, POSITIVE ,TRANSFLECTIVE
Viewing Direction:12.00 O’clock
LCD Driving Method:1/4 Duty, 1/3 Bias, 3.0V
Driver IC:ST7565R
Product description: Power Meters Reflective Indicator HTN LCD
INQUIRY

Power Meters Reflective Indicator HTN LCD

This HTN LCD display is used in medical sphygmomanometers, in financial electronic POS machines, thermometers in instrumentation, voltage controller panels, electronic products such as electronic calendars.

The display parameters in the table below refer to the dimensions of the figure below. If you have other requirements, you can tell us the parameters such as size, or tell us the products you need to adapt. We can provide you with the right model for you to choose.

General Specification

P/N	SDH-13304-HP-4
Power Supply	3.0V
Display Type	HTN, POSITIVE ,TRANSFLECTIVE
Viewing Direction	12.00 O’clock
LCD Driving Method	1/4 Duty, 1/3 Bias, 3.0V
Driver IC	ST7565R
Input Data	Parallel 6800 Series MPU Interface / Parallel 8080 Series MPU Interface / Serial 4-Line SPI Interface
Module Size(WHT)	170*57.6mm
GLASS THICKNESS	1.1
CONNECTOR	PIN
