Display Format |
128*128 DOTS |
|
Power Supply |
3.0 V |
|
Display Type |
FSTN, Positive, Transflective |
|
Viewing Direction |
12 O'clock |
|
LCD Driving Method |
1/128 Duty, 1/11 Bias,13.5 V |
|
Driver IC |
UC1617S |
|
Input Data |
Serial |
|
Module Size(W*H*T) |
51.9*57.38*4.0 mm |
|
Viewing Area (W*H) |
46.68*45.78mm |
|
Active Area (W*H) |
40.94*40.94mm |
|
Dot Size (W*H) |
0.30*0.30mm |
|
Dot Pitch (W*H) |
0.32*0.32mm |
|
Backlight |
sidelight ,White, 4PCS,LED, 60mA,3.1 V(TYP.) |
Model
Content
Module size
View area
Dot size
Dot pitch
Driving Method
Controller LSI or Equiv
IC
STN-TYPE
FSTN-TYPE
8D -C2004A
20X4
98.0X60.0
76.0X25.2
0.55X0.55
2.95X4.75
1/16
S6A0069
COB
Y
Y
8D -C2004B
20X4
77.0X47.0
60.0X22.0
0.42X0.46
2.3X4.03
1/16
S6A0070
COB
Y
Y
8D -C2004C
20X4
146.0X62.5
123.5X43.0
0.92X1.1
4.84X9.22
1/16
S6A0069
COB
Y
Y
8D -C2402A
24X2
118.0X36.0
93.5X16.0
0.6X0.65
3.2X5.55
1/16
S6A0069
COB
Y
Y
8D -C2402B
24X2
208.0X40.0
178.0X23.0
1.16X1.16
6.0X9.63
1/16
S6A0069
COB
Y
Y
8D -C4001A
40X1
182.0X33.5
154.4X16.5
0.6X0.75
3.2X6.35
1/16
S6A0069
COB
Y
Y
8D -C4002B
40X2
182.0X33.5
154.4X16.5
0.6X0.65
3.2X5.55
1/16
S6A0069
COB
Y
Y
8D C4004A
40X4
190.0X54.0
147.0X29.5
0.5X0.55
2.78X4.89
1/16
S6A0069
COB
Y
Y
8D -G12232A
122X32
84.0X44.0
60.0X18.5
0.4X0.4
0.44X0.44
1/32
SED1520
COB
Y
Y
8D -G12232B
122X32
80.0X36.0
55.0X18.5
0.36X0.41
0.4X0.45
1/32
SED1520
COB
Y
Y
8D -G12232C
122X32
98.0X60.0
76.0X25.2
0.53X0.61
0.57X0.65
1/32
SED1520
COB
Y
Y
8D -G12232D
122X32
80.2X47.4
76.0X25.2
0.53X0.61
0.57X0.65
1/32
SED1520
COB
Y
Y
8D -G12864A
128X64
78.0X70.0
62.0X44.0
0.39X0.55
0.44X0.6
1/64
S6B0108A
COB
Y
Y
8D -G12864B
128X64
105.0X60.5
72.0X40.0
0.48X0.48
0.52X0.52
1/64
S6B0108A
COB
Y
Y
8D -G12864C
128X64
93.0X70.0
72.0X40.0
0.48X0.48
0.52X0.52
1/64
S6B0108A
COB
Y
Y
8D -G12864D
128X64
113.0X65.0
72.0X40.0
0.48X0.48
0.52X0.52
1/64
S6B0108A
COB
Y
Y
8D -G12864E
128X64
93.0X70.0
72.0X40.0
0.48X0.48
0.52X0.52
1/64
ST7920
COB
Y
Y
8D -G19264A
192X64
130X65.0
104.0X39.0
0.46X0.46
0.51X0.51
1/64
S6B0108A
COB
Y
Y
8D -G19264B
192X64
120X62.0
104.0X39.0
0.46X0.46
0.51X0.51
1/64
S6B0108A
COB
Y
Y
8D -G24064B
240X64
180.0X65.0
132.0X39.0
0.53X0.53
0.49X0.49
1/64
T6963C
QFP/COB
Y
Y
8D -G240128A
240X128
144X104
114X64
0.4X0.4
0.45X045
1/128
T6963C
QFP/COB
Y
Y
(W X H)
W x H(mm)
W x H(mm)
W x H(mm)
W x H(mm)
Package
